Dedacciai Road EDG DCR Fork

Dedacciai

$555.00

Description

EDG DB DCR fork is designed to be compatible with a road bicycle frame. It is designed to be compatible with both standard stems and DCR (Deda Cable Routing) stems, allowing for different cable routing options. Specifically, it supports: standard stems (up to 3 cables, which can include two brake housing cables and one mechanical or electronic shifting cable); DCR stems (up to 4 cables, accommodating two brake housing cables and two shifting cables - mechanical or electronic). Available in raw finish.

DOWNLOADABLE RESOURCES

Dedacciai Road EDG DCR Fork

EDG DB DCR Tech Specs

DCR Forks Use and Maintenance Manual

THE DETAILS

Dedacciai Road EDG DCR Fork SPECS

Spec:

Material: Full carbon fiber

Fork Steerer: D-Shape 1" 1/8

Headset Compatibility: Upper bearing 1" 1/8; lower bearing 1.5". 45° integrated crown race

Steerer Length: 350mm

Axle-Crown Length: 369mm

Rake: 45mm

Axle Compatibility: 100x12mm thru-axle

Crown Diameter: 56mm

Disc Brake Rotor Compatibility: Flat mount, 140mm or 160mm

Finish: Raw

Accessories Included: Thru-axle (M12xP1.5x120), Dedacciai "EXP" 23.5mm and topcap

Weight: 414g (460g painted + screws)

Frames Compatibility: Any bicycle frame featuring internal cable routing system and fitting Deda DCR headset, Deda Classic 1 or tapered 1" 1/8-1.5" / 1" 1/4-1.5" / 1.5"-1.5"

Bearings Compatibility: Upper, headset/frame headtube with 1" 1/8, 1" 1/4 or 1.5"; Lower, 1.5" bearing; 45° contact angle bearing

Stems Compatibility: All Deda stems or stems with a large opening between the fork steerer and stem body to allow internal cable routing

Wheels and Tires Compatibility: Max tire clearance 622x28mm (28"x1.1")

Internal Cable Routing: With a standard stem up to 3 cables (two brake housing cables and mechanical/electronic shifting cable); with a DCR stem up to 4 cables (two brake housing cables and two shifting cables)

Wheel Centering Tolerance: +/- 1.5mm
