Dedacciai Gera Curvy DCR Fork

Dedacciai

$630.00

Description

Gera Curvy is the perfect gravel fork for adventure and bikepacking in which all the details have been designed with the aim of responding to a specific need. The first gravel fork fitting a 180mm rotor disc to guarantee the best possible braking even under heavy load conditions. The fork has been designed to allow the integration of the cables inside the frame thanks to a D-shape fork steerer and the DCR system.

It is compatible with most of the frames on the market, both carbon and metal. It features a full carbon construction with an integrated 45° crown race, triple cage mounts on each fork blade for bikepacking front bags as well as inserts for fender mounts. Tire clearance up to 57mm (29”) or 65mm (27.5”). It is ready for dynamo hubs, such as SON®, for optimal integration of the electric cables inside the fork.

DOWNLOADABLE RESOURCES

Dedacciai Gera Curvy DCR Fork

DCR Forks Use and Maintenance Manual

EDG Road, Allroad, Gera Curvy & Gera EDG Spare Parts Catalog

Gera Curvy Tech Specs

THE DETAILS

Dedacciai Gera Curvy DCR Fork SPECS

Spec:

Material: Full carbon fiber, UD finish

Fork Steerer: D-Shape 1" 1/8

Headset Compatibility: Upper bearing 1" 1/8; lower bearing 1.5". 45° integrated crown race

Steerer Length: 350mm

Axle-Crown Length: 398mm

Rake: 50mm

Axle Compatibility: 100x12mm thru-axle (included)

Crown Diameter: 56mm

Disc Brake Rotor Compatibility: Flat mount, 160mm or 180mm

Max. Fork Load: 15 kg per side (5 kg per eyelet)

Finish: UD carbon with POB logo

Accessories Included: Thru-axle (M12xP1.5x120), D-shape custom expander and topcap

Weight: 545g

Note: Fender mounts, ready for SON dynamo hub

Frames Compatibility: Any bicycle frame featuring internal cable routing system and fitting Deda DCR headset, Deda Classic 1, Classic 2 or tapered 1" 1/8-1.5" / 1" 1/4-1.5" / 1.5"-1.5"

Stems Compatibility: All Deda stems or stems with a large opening between the fork steerer and stem body to allow internal cable routing

Wheel and Tire Compatibility: 622x57 (29"x2.25"), 584x65 (27.5"x2.6"), depending on tire/rim manufacturer

Bearings Compatibility: Upper, headset/frame headtube with 1" 1/8, 1" 1/4 or 1.5"; Lower, 1.5" bearing; 45° contact angle bearing

Internal Cables Routing: With a standard stem up to 3 cables (two brake housing cables and mechanical/electronic shifting cable); with a DCR stem up to 4 cables (two brake housing cables and two shifting cables)

Minimum Tire Clearance at Fork Blade: 10mm (29"x2.25"), 8mm (27.5"x2.6")

Wheel Centering Tolerance: +/- 1.5mm
