Dedacciai Allroad DCR Fork

Dedacciai

$630.00

Description

Allroad is a superlight fork ideal for allroad use. The design facilitates the integration of cables inside the frame, thanks to its D-shape fork steerer and the DCR system. Compatible with most bicycle frames on the market, whether they are made of carbon or metal. Its full carbon construction, coupled with an integrated 45° crown race, ensures both strength and lightweight performance. It is designed to accommodate dynamo hubs, such as the SON®, allowing for optimal integration of electric cables inside the fork.

DOWNLOADABLE RESOURCES

Dedacciai Allroad DCR Fork

DCR Forks Use and Maintenance Manual

EDG Road, Allroad, Gera Curvy & Gera EDG Spare Parts Catalog

Allroad - Notice

THE DETAILS

Dedacciai Allroad DCR Fork SPECS

Spec:

Material: Carbon monocoque, UD finish

Fork Steerer: D-Shape 1" 1/8

Headset Compatibility: Upper bearing 1" 1/8; lower bearing 1.5". 45° integrated crown race

Steerer Length: 350mm

Axle-Crown Length: 370mm

Rake: 45mm

Axle Compatibility: 100x12mm thru-axle (included)

Crown Diameter: 56mm

Disc Brake Rotor Compatibility: Flat mount, 140mm or 160mm

Finish: UD carbon with POB logo

Accessories Included: Thru-axle (M12xP1.5x115.5), D-shape custom expander and topcap

Weight: 420g

Note: Fender mounts, ready for SON dynamo hub

Frames Compatibility: Any bicycle frame featuring internal cable routing system and fitting Deda DCR headset, Deda Classic 1 or tapered 1" 1/8-1.5" / 1" 1/4-1.5" / 1.5"-1.5"

Stems Compatibility: All Deda stems are compatible, or stems with a large opening between the fork steerer and stem body to allow internal cable routing

Wheel and Tire Compatibility: 622x35 (28"x1.35"), depending on tire/rim manufacturer

Bearings Compatibility: Upper, headset/frame headtube with 1" 1/8, 1" 1/4 or 1.5"; Lower, 1.5" bearing; 45° contact angle bearing

Internal Cables Routing: With a standard stem up to 3 cables (two brake housing cables and mechanical/electronic shifting cable); with a DCR stem up to 4 cables (two brake housing cables and two shifting cables)

Minimum Tire Clearance at Fork Blade: 5mm (28"x1.35")

Wheel Centering Tolerance: +/- 1.5mm
